Feuling Quick-Install Pushrods

Feuling Quick-Install Pushrods

• Strength and rigidity of Quick Install pushrods are second only to heavy-duty one-piece pushrods

• Tube material starts out as 7/16” rod OD, then gets turned down to 3/8” OD leaving heavy duty 7/16” - 20 threads for the base and jam nut

• 0.134” wall thickness

• Jam nut slides up the pushrod

• Base then loosens up into the pushrod to allow Quick Install access

• Individual length exhaust and intake pushrods

• Install without the removal of rocker covers

• Correct pushrod/lifter adjustment requires starting with fully pumped up lifters.

• Quick Install pushrods have 7/16” - 20 threads per inch. 0.050” adjustment per turn. Two turns = 0.100”.
